FMS – Oxygen O2

Name: FMS - Oxygen O2
SKU: 25
Price: 3670.00 AED
Availability: InStock

~~5,000.00AED~~ 3,670.00AED

Facility Monitoring System – With I2C and MODBUS

Description

TECHNICAL SPECIFICATION
Power supply	13V DC ±10% \| 110-230V 50Hz/60Hz AC UL
Power safe	Li Battery 4 AH[optional], Auto-shut down super capacitor protection
Working memory	1GB \| 2GB \| 4GB
Storage	64GB class 3
Extended storage	256GB SSD [Optional]
Cloud	Amazon AWS Dedicated server
Out put control	8x 10A 220V \| 5A 30V DC, Dry contact out
Working Temperature	– 10°C up to 60°C
Connectivity	IEEE 802.11.b/g/n/ac wireless LAN 2.4GHz and 5GHz Bluetooth 4.2/BLE, faster Ethernet
Processor power	Quad-core processor, Cortex-A53 (ARMv8) 64-bit SoC @ 1.4GHz
Ports	1x HDMI 1.4, 4xUSB 2.0 ports
Input / Output	8x Dry contact out put Digital out 8x Digital logical input – Isolated industrial 128x Digital input expansion over i2C [optional]
Dimension [HxWxD]	46mm x 482mm x 90mm
External connections Protocols	I2C, 1Wire, TCPIP, Wifi, MODBUS[optional], Zigbee[optional] Zwave[optional], MQTT, GPIO, HDMI-Audio video, 433Mhz RF
Integration	amazon echo, Google Home, Apple Home kit, Grafana, HTML5, NODE JS, Python, MQTT, Node Red, Artificial Intelligence
